Model：AC
The technology is mature, with strong overload resistance, suitable for high-temperature and high-humidity environments. It is easy to maintain and has a low cost, making it an ideal choice for stable and durable economic dryers.
| Technical parameter | ||||
|---|---|---|---|---|
| NO | ITEM | AC Dryer Motor | BLDC Dryer Motor | Tumble Dryer Motor with Centrifugal switch |
| 1 | Driving mode | Horizontal direct drive | Horizontal direct drive | Horizontal direct drive |
| 2 | Insulation grade | CLASSF | CLASSF | CLASSF |
| 3 | Stator poles | 4P/2P | 18P | 4P |
| 4 | Rotor poles | 4P/2P | 8P/10P | 4P |
| 5 | Power | 3/2～1/4HP | 1/5HP | 1/5～1/3HP |
| 6 | Motor Efficiency |
>58% |
≥85% |
≥50% |
| 7 | Torque |
0.41~1.30N.m |
0.53N.m |
0.81~1.30N.m |
| 8 | Transmission structure | 2POLE/1POLE,AL | 2POLE/1POLE,AL | 1POLE |
| 9 | Speed rang | – | – | 1630~1725rpm |
Nanyang advantages:
Nanyang has achieved in-house production of core motor components including
1) Enamelled wire including copper and aluminium
2) Stator & Rotot core
3) Injected molding (more than 130 injection molding machines)
4) Aluminum die casting
5) Sheet metal stamping
We established strategic alliances with leading steel groups – significantly optimizing our raw material costs while ensuring premium quality.
You can provide your product requirements to our sales team, and we will select or design the most suitable combination solution for you.
