Model：BLDC
Nanyang pushes the boundaries of dryer performance with a next-gen motor-BPM Dual Rotor Motor,designed for the high-end market.with good performance, reliability, and energy efficiency 1)Independent control of drum and fan 2)Interchangeable with single motor: no redesign needed! 3)High efficiency, low noise, and real-time feedback 4)Supports variable speed up to 3,500 rpm to gently dry delicate fabrics 5)Compact, lightweight, Plug & Play system with soft start
Variable frequency technology significantly reduces energy consumption while achieving extremely low operating noise and vibration. The motor supports stepless speed regulation and precise reverse rotation, which can effectively prevent clothes from tangling, achieve uniform and gentle drying, and significantly enhance the care effect and user experience.
| Technical parameter | ||||
|---|---|---|---|---|
| NO | ITEM | AC Dryer Motor | BLDC Dryer Motor | Tumble Dryer Motor with Centrifugal switch |
| 1 | Driving mode | Horizontal direct drive | Horizontal direct drive | Horizontal direct drive |
| 2 | Insulation grade | CLASSF | CLASSF | CLASSF |
| 3 | Stator poles | 4P/2P | 18P | 4P |
| 4 | Rotor poles | 4P/2P | 8P/10P | 4P |
| 5 | Power |
3/2～1/4HP |
1/5HP |
1/5～1/3HP |
| 6 | Motor Efficiency |
>58% |
≥85% |
≥50% |
| 7 | Torque | 0.41~1.30N.m | 0.53N.m | 0.81~1.30N.m |
| 8 | Transmission structure | 2POLE/1POLE,AL | 2POLE/1POLE,AL | 1POLE |
| 9 | Speed rang | – | – | 1630~1725rpm |
Nanyang advantages:
Nanyang has achieved in-house production of core motor components including
1) Enamelled wire including copper and aluminium
2) Stator & Rotot core
3) Injected molding (more than 130 injection molding machines)
4) Aluminum die casting
5) Sheet metal stamping
We established strategic alliances with leading steel groups – significantly optimizing our raw material costs while ensuring premium quality.
You can provide your product requirements to our sales team, and we will select or design the most suitable combination solution for you.
