Spin Motor
Model：Semi-automatic motor
１) Simple and rugged construction 2) Low cost and minimum maintenance 3) High dependability and sufficiently high proficiency 4) Needs no additional starting motor and necessity not to be synchronized
Contact
Us
Product Introduction
Single-phase induction motors are the most common type of AC motors,widely used in home appliances.
Key Features:
Operates on single-phase AC supply.
Simple construction,reliable, and cost-effective
Stack height from 16mm to 60mm
Applications: twin tub washing machine/spin dryer
Product Parameters
| Technical parameter | ||
|---|---|---|
| NO | ITEM | Semi-automatic wash machine motor |
| 1 | Voltage | 110V、170V、220V、230V、240V、220—240V |
| 2 | Rated Frequency | 50Hz、60Hz、50/60Hz |
| 3 | Rated Power | 25~250W |
| 4 | Winding | Aluminium、Copper |
| 5 | Insulation Class |
ClassF、ClassB |
| 6 | Number Poles |
4P、6P |
| 7 | Character of Service | S1、S2/15min |
| 8 | Noise | ≤50dB |
| 9 | Ambient Temperature | -15℃—40℃ |
| 10 | Altitude | ≤1000m |
Nanyang advantages:
Nanyang has achieved in-house production of core motor components including
1) Enamelled wire including copper and aluminium
2) Stator & Rotot core
3) Injected molding (more than 130 injection molding machines)
4) Aluminum die casting
5) Sheet metal stamping
We established strategic alliances with leading steel groups – significantly optimizing our raw material costs while ensuring premium quality.
Technical Illustration
You can provide your product requirements to our sales team, and we will select or design the most suitable combination solution for you.
